Automatic Car Washer – Smartwash
Features & BenefitsSpecificationsVariantsCatalogueVideoRequest a Quote
- Stainless Steel precision nozzles
- Wax to improve reflective index
- Optimized flow control in side and top blower
- Increased Productivity( 3-7 minute operation time)
- Reduced water consumption ( 85 liters to 130 liters per car )
- Reduced labor costs ( Only one operator needed )
| SPECIFICATIONS | SMART WASH | |
|---|---|---|
| NO OF BRUSHES | Vertical brush | 2 Nos |
| Horizontal brush | 1Nos | |
| RECOMMENDED BAY DIMENSION | Length | 10000 mm |
| Width | 4600 mm | |
| Height | 5000 mm | |
| MAX. VEHICLE ACCESS | Length | 5200 mm |
| Width | 2000 mm | |
| Height | 2300 mm | |
| WASHING SYSTEM | PLC AUTOMATION | |
| BRUSH MATERIAL | Polyethylene | |
| SHAMPOO / WAX MIXING CONTROLS | Venturi system | |
| DRYING | Type | Automatic |
| Parameters | Smart Wash HP | Smart Wash FP | Smart Wash SP | Smart Wash EP |
|---|---|---|---|---|
| High Pressure Pre Wash | ✔ | ✘ | ✘ | ✘ |
| Body Wash | ✔ | ✔ | ✔ | ✔ |
| Wheel Wash | ✔ | ✔ | ✘ | ✘ |
| Drying | ✔ | ✔ | ✔ | ✘ |
| Under Chassis Washer (Optional) | ✔ | ✔ | ✔ | ✔ |
| Shampoo | ✔ | ✔ | ✔ | ✔ |
| Wax | ✔ | ✔ | ✔ | ✘ |
| HMI Touchscreen Operating Panel | ✔ | ✔ | ✔ | ✔ |
| Cycle Time Per Car, Min | 6 - 7 | 5 - 6 | 5 - 6 | 3 - 4 |
| Water Consumption Per Car, L | 120 - 130 | 85 - 100 | 85 - 100 | 85 - 100 |
| Power Supply | 3ph 415VAC( +10%, -15%), 50Hz | 3ph 415VAC( +10%, -15%), 50Hz | 3ph 415VAC( +10%, -15%), 50Hz | 3ph 415VAC( +10%, -15%), 50Hz |
| Connected Load | 29.5/22 HP/kW | 22/16.5 HP/kW | 21.5/16 HP/kW | 5.5/4 HP/kW |
| Maximum Operating Load | 18/13.5 HP/kW | 18/13.5 HP/kW | 18/13.5 HP/kW | 5.5/4 HP/kW |
| Power Consumption | 0.8 | 0.7 | 0.7 | 0.2 |
| Air Requirement | 7 bar/ 5 CFM | 7 bar/ 5 CFM | 7 bar/ 5 CFM | 7 bar/ 5 CFM |
